Name: VMPAC-AP-14-B-2
Brand: Festo
SKU: 576575
Availability: InStock

sub-base VMPAC-AP-14-B-2 Width=32,8 mm, Length=169 mm, Grid dimension=26,8 mm, Max. number of valve positions=1, Operating pressure=-0,9 – 8 bar

Width	32.8 mm
Length	169 mm
Grid dimension	26.8 mm
Max. number of valve positions	1
Operating pressure	‘-0.9 … 8 bar
Pilot pressure	3 … 8 bar
Corrosion resistance classification CRC	4 – Very high corrosion stress
Ambient temperature	‘-5 … 50 °C
Product weight	160 g
Pneumatic connection, port 2	G1/4
Pneumatic connection, port 4	G1/4
Materials note	Conforms to RoHS
Material housing	PA-reinforced

Weight	0.429703 lbs
Dimensions	8.858268 × 4.527559 × 1.574803 in
Width	32.8 mm
Length	169 mm
Grid dimension	26.8 mm
Max. number of valve positions	1
Operating pressure	-0.9 … 8 bar
Pilot pressure	3 … 8 bar
Corrosion resistance classification CRC	4 – Very high corrosion stress
Ambient temperature	-5 … 50 °C
Product weight	160 g
Pneumatic connection, port 2	G1/4
Pneumatic connection, port 4	G1/4
Materials note	Conforms to RoHS
Material housing	PA-reinforced
