In addition to the Original Pancake cylinder, FABCO-AIR designs and delivers linear slides, actuators, air preparation units, valves and more - all with short lead times on both custom and off-the-shelf units.
Compact Air Cylinder
Original PancakeĀ®
- Pressure rated to 250 psi pneumatic and 500 psi hydraulic service
- Heavy wall to protect the bore from damage
- Clear anodized cylinder bodies: smooth corrosive-resistant exterior prevents debris buildup
- Hard chrome-plated stainless steel piston rod adds longevity to the cylinder
Round Body Air Cylinder
F-Series
- Strokes: up to 32 inches
- 304 stainless steel air cylinder tube drawn and polished for low friction and long life
- Buna-N U-cup rod and piston seals
- 303 stainless steel, ground, polished, and roller burnished cylinder rods standard
NFPA Standard Actuators
NFPA & FCQN
- Interchangeable with NFPA standard dimensions
- Magnetic pistons for position sensing
- NFPA Series models: All stainless steel, tandem cylinders, three-position and back-to-back models
- Lubricated with Magnalube-G Teflon-impregnated grease
Round Body Air Cylinders
H Series Humphrey Interchange
- Strokes up to 12 inches
- Legacy actuator for applications where an F Series roundbody cylinder is not an option
- Pressure rated to 200 psi pneumatic service
- Magnetic piston option for cylinder position sensing
Direct Interchange Air Cylinder
PancakeĀ® II
- Strokes up to 9 inches
- Effective output motion with short strokes for space-constrained applications
- impact-resistant composite cylinder barrel
- Hard chrome-plated stainless steel piston rod
