pressure regulator LR-D-MAXI without threaded connecting plates. Size=Maxi, Series=D, Actuator lock=Rotary knob with lock, Design structure=Piloted piston regulator, Controller function=(* Output pressure constant, * with secondary exhaust)
| Size | Maxi |
|---|---|
| Series | D |
| Actuator lock | Rotary knob with lock |
| Design structure | Piloted piston regulator |
| Controller function | Output pressure constantwith secondary exhaust |
| Pressure gauge | Prepared for G1/4 |
| Operating pressure | 0 … 16 bar |
| Pressure regulation range | 0.5 … 12 bar |
| Standard nominal flow rate | 11,500 l/min |
| Operating medium | Compressed air in accordance with ISO8573-1:2010 [7:4:4]Inert gases |
| Note on operating and pilot medium | Lubricated operation possible (subsequently required for further operation) |
| Air purity class at output | Compressed air in accordance with ISO8573-1:2010 [7:4:4]Inert gases |
| Medium temperature | ‘-10 … 60 °C |
