solenoid valve MHA1-M1H-2/2G-0,9-HC manifold block valve for individual and battery mounting, particularly small design, with plug connection at rear. Valve function=2/2 closed, monostable, Type of actuation=electrical, Width=10 mm, Standard nominal flow rate=14 l/min, Operating pressure=-0,9 – 2 bar
| Valve function | 2/2 closed, monostable |
|---|---|
| Type of actuation | electrical |
| Width | 10 mm |
| Standard nominal flow rate | 14 l/min |
| Operating pressure | ‘-0.9 … 2 bar |
| Design structure | Poppet valve with spring return |
| Type of reset | mechanical spring |
| Protection class | IP40 |
| Authorisation | c CSA us – Recognized (OL)c UL us – Recognized (OL) |
| Nominal size | 0.9 mm |
| Grid dimension | 10 mm |
| Exhaust-air function | not throttleable |
| Sealing principle | soft |
