| Brands | Air Logic |
|---|---|
| Filter Size | 43 µm |
| Color | Light Blue |
| Maximum Pressure | 125 psi8.6 bar |
| Typical Tube Retention Pressure1 | 125 psi8.6 bar |
| Filtration | 43 µm |
| Tubing Inside Diameter (ID) | 1/8 in |
| Connection Type | Barbed |
| Wetted Material(s) | Polysulfone (PSU) Stainless Steel (SS) |
| Installation Method | Push-In |
| Connection Size | 10-32 Threads |
| EU RoHS 2 (Directive 2011/65/EU with amendment (EU) 2015/863) | Yes |
| REACH (Registration, Evaluation, Authorization and Restriction of Chemicals) Compliant | Yes |
| Additional Information | This filter is well suited to filtering media entering or leaving a critical device. Integrate the threaded filter into a system to create a filtered input or output. Ex. Regulator, Valve, cylinder, or pump.
Threaded in-line filters are commonly used to protect against debris generated inside of a system or device. Ex. Polytetrafluoroethylene (PTFE) tape debris during assembly, broken O-rings from valves, machining chips from threads. |
