| Weight | 5.467464 lbs |
|---|---|
| Dimensions | 15.748031 × 10.629921 × 3.149606 in |
| Mounting position | Any |
| Grade of filtration | 0.01 µm |
| Configuration support | Python scripts |
| Display | LED |
| Output pressure 1 | -0.062 MPa |
| Output pressure 2 | 0.08 MPa |
| Standard flow rate (standardized according to DIN 1343) | <1.2 l/min |
| Dimensions W x L x H | 169 mm x 208 mm x 55 mm |
| DC operating voltage range | 21.6 V … 26.4 V |
| Electrical power consumption | 11 W |
| Nominal operating voltage DC | 24 V |
| Permissible voltage fluctuations | +/- 10 % |
| Power supply, function | Load and functional earth |
| Power supply, type of connection | Socket |
| Power supply, connection technology | Terminal strip |
| Power supply, number of pins/wires | 5 |
| Power supply, connection pattern | 00997301 |
| Certification | RCM compliance mark |
| CE marking (see declaration of conformity) | As per EU EMC directive, As per EU RoHS directive |
| UKCA marking (see declaration of conformity) | To UK instructions for EMC, To UK RoHS instructions |
| Vibration resistance | Transport application test with severity level 2 as per FN 942017-4 and EN 60068-2-6 |
| Shock resistance | Shock test with severity level 2 as per FN 942017-5 and EN 60068-2-27 |
| Corrosion resistance class (CRC) | 0 – No corrosion stress |
| LABS (PWIS) conformity | VDMA24364 zone III |
| Storage temperature | -20 °C … 70 °C |
| Relative air humidity | 0 – 85 % |
| Sound power level | 55 dB(A) |
| Degree of protection | IP20 |
| Ambient temperature | 0 °C … 40 °C |
| Product weight | 1800 g |
| Electrical actuation | Integrated controller |
| Type of mounting | With internal thread M4 |
| Pneumatic connection 1 | QS-4 |
| Pneumatic connection 2 | QS-4 |
| Pneumatic connection, number | 2 |
| Housing colour | Gray |
| Note on materials | RoHS-compliant |
| Housing material | Aluminum, powder-coated |
