Stroke | 10 mm |
---|---|
Piston diameter | 16 mm |
Piston rod thread | M6 |
Cushioning | Elastic cushioning rings/pads at both ends |
Mounting position | Any |
Conforms to standard | ISO 6432 |
Piston rod end | External thread |
Structural design | Piston Piston rod Cylinder barrel |
Position sensing | For proximity sensor |
Symbol | 00991217 |
Operating pressure | 0.1 MPa … 1 MPa |
Operating pressure | 1 bar … 10 bar |
Mode of operation | Double-acting |
Operating medium | Compressed air as per ISO 8573-1:2010 [7:4:4] |
Information on operating and pilot media | Operation with oil lubrication possible (required for further use) |
Corrosion resistance class (CRC) | 3 – high corrosion stress |
Ambient temperature | -20 °C … 80 °C |
Impact energy in the end positions | 0.15 J |
Theoretical force at 6 bar, retracting | 104 N |
Theoretical force at 6 bar, advancing | 121 N |
Moving mass at 0 mm stroke | 21 g |
Additional moving mass per 10 mm stroke | 2 g |
Basic weight with 0 mm stroke | 130 g |
Additional weight per 10 mm stroke | 5 g |
Type of mounting | With accessories |
Pneumatic connection | M5 |
Note on materials | RoHS-compliant |
Cover material | High-alloy stainless steel |
Piston rod material | High-alloy stainless steel |
Material of cylinder barrel | High-alloy stainless steel |
