| Width | 96 mm |
|---|---|
| Height | 130 mm |
| Length | 179 mm |
| Mounting position | Free convection |
| Primary supply | 3-phase |
| Input current | 1.7 – 2.1 A |
| Nominal output voltage DC | 48 V |
| Nominal output current | 20 A |
| Input voltage range AC | 400 V … 500 V |
| Power failure buffering | 25 ms |
| Mains frequency | 45 Hz … 65 Hz |
| Certification | c UL us – Listed (OL) |
| CE marking (see declaration of conformity) | As per EU EMC directive As per EU low voltage directive |
| LABS conformity | VDMA24364 zone III |
| Storage temperature | -40 °C … 85 °C |
| Relative air humidity | 95 % |
| Degree of protection | IP20 |
| Ambient temperature | -25 °C … 70 °C |
| Product weight | 2500 g |
| Type of mounting | With H-rail |
| Note on materials | RoHS-compliant |
| Weight | 6.448257 lbs |
|---|---|
| Dimensions | 10.748031 × 7.244094 × 6.889764 in |
