Width | 42 mm |
---|---|
Height | 130 mm |
Length | 160 mm |
Mounting position | Free convection |
Primary supply | 1-phase |
Input current | 1.2 – 2.9 A |
Nominal output voltage DC | 48V |
Nominal output current | 5A |
Input voltage range AC | 100V |
Power failure buffering | 15ms |
Mains frequency | 45Hz |
Certification | c UL us – Listed (OL) |
CE marking (see declaration of conformity) | As per EU EMC directive |
LABS (PWIS) conformity | VDMA24364 zone III |
Storage temperature | -40°C |
Relative air humidity | 95 % |
Degree of protection | IP20 |
Ambient temperature | -25°C |
Product weight | 1120g |
Type of mounting | With H-rail |
Note on materials | RoHS-compliant |
