Stroke | 10 mm |
---|---|
Piston diameter | 10 mm |
Cushioning | No cushioning |
Mounting position | Any |
Mode of operation | Double-acting |
Piston rod end | Internal thread |
Structural design | Piston Piston rod |
Position sensing | For proximity sensor |
Symbol | 00991216 |
Variants | Recommended for production facilities for the manufacture of lithium-ion batteries Piston rod at one end |
Operating pressure | 0.1 MPa … 0.8 MPa |
Operating pressure | 1 bar … 8 bar |
Operating pressure | 14.5 psi … 116 psi |
Operating medium | Compressed air as per ISO 8573-1:2010 [7:4:4] |
Information on operating and pilot media | Operation with oil lubrication possible (required for further use) |
Corrosion resistance class (CRC) | 2 – Moderate corrosion stress |
RSBP classification to CD-0033 | F1a |
Cleanroom class | ISO Class 6 |
Ambient temperature | -10 °C … 60 °C |
Impact energy in the end positions | 0.012 J |
Theoretical force at 6 bar, retracting | 30.2 N |
Theoretical force at 6 bar, advancing | 47 N |
Moving mass | 5.7 g |
Product weight | 17.7 g |
Type of mounting | With through-hole |
Pneumatic connection | M3 |
Note on materials | RoHS-compliant |
Cover material | Wrought aluminum alloy |
Material of dynamic seals | NBR TPE-U(PU) |
Housing material | Wrought aluminum alloy, anodized Anodized |
Piston rod material | High-alloy stainless steel |
