| Actuation type | Electrical |
|---|---|
| Mounting position | Any |
| Duty cycle | 100% |
| Insulation class | F |
| Enameled wire insulation class | H |
| Coil characteristics | 24 V DC: 2.6 W |
| Permissible voltage fluctuations | +/- 10 % |
| Maritime classification | See certificate |
| CE marking (see declaration of conformity) | as per EU explosion protection directive (ATEX) |
| UKCA marking (see declaration of conformity) | acc. to UK EX instructions |
| Explosion protection certification outside the EU | EPL Db (GB) |
| Explosion prevention and protection | Zone 1 (ATEX) |
| Certificate issuing authority | IECEx PTB 15.0016X |
| ATEX category gas | II 2G |
| ATEX category for dust | II 2D |
| Type of ignition protection for gas | Ex mb IIC T6 Gb |
| Type of (ignition) protection for dust | Ex mb tb IIIC T80°C Db |
| Explosive ambient temperature | -20°C <= Ta <= +50°C |
| Corrosion resistance class (CRC) | 2 – Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B2-L |
| Degree of protection | IP65 |
| Ambient temperature | -20°C |
| Product weight | 762g |
| Electrical connection | Cable |
| Cable diameter | 7mm |
| Cable length | 10m |
| Type of mounting | With knurled nut |
| Note on materials | RoHS-compliant |
| Housing material | Polymer |
| Material of winding | Copper |
| Weight | 1.876134 lbs |
|---|---|
| Dimensions | 9.448819 × 9.448819 × 0.11811 in |
