| Mounting position | Any |
|---|---|
| Structural design | Pneumatic muffler, open |
| Symbol | 00991473 |
| Operating pressure | 0 MPa … 0.8 MPa |
| Operating pressure | 0 bar … 8 bar |
| Operating medium | Compressed air as per ISO 8573-1:2010 [7:4:4] |
| LABS conformity | VDMA24364-B1/B2-L |
| Ambient temperature | -10 °C … 60 °C |
| Product weight | 0.5 g |
| Pneumatic connection | M5 |
| Cushioning insert material | PE |
| Material of screwed trunnion | PE |
| Note on materials | Free of copper and PTFE RoHS-compliant |
| Weight | 0.001565 lbs |
|---|---|
| Dimensions | 0.787402 × 0.314961 × 0.314961 in |
| Material shock absorber insert | PE |
| Pneumatic connection | M5 |
| Operating pressure | 0 bar – 8 bar |
| Ambient temperature | -10?C – 60?C |
