| Adjustment range of swivel angle | 0 deg … 180 deg |
|---|---|
| Connection point for positioner and position sensor conforms to standard | VDI/VDE 3845 size AA 1 |
| Dimensions W x L x H | Ø 40 x 32 |
| Vibration resistance | Transport application test with severity level 2 as per FN 942017-4 and EN 60068-2-6 |
| Shock resistance | Shock test with severity level 2 as per FN 942017-5 and EN 60068-2-27 |
| Ambient temperature | -25 °C … 70 °C |
| Product weight | 24 g |
| Type of mounting | as per VDI/VDE 3845 |
| Housing colour | Black |
| Note on materials | Contains paint-wetting impairment substances RoHS-compliant |
| Spacer element material | PP |
| Housing material | PP High-alloy stainless steel |
| Material of screws | High-alloy stainless steel |
| Weight | 0.05441 lbs |
|---|---|
| Dimensions | 1.574803 × 1.574803 × 1.181102 in |
