| Contamination level | 2 |
|---|---|
| Insulating sheath material | PVC |
| Permissible voltage fluctuations | +/- 10 % |
| Size | 7 |
| Bending radius, fixed cable installation | ≥ 11 mm |
| Bending radius, flexible cable installation | ≥ 16.5 mm |
| Type code | VAVE |
| Mounting position | Any |
| Cable characteristic | Basic |
| Reverse polarity protection | for operating voltage |
| Additional functions | Holding current reduction |
| Signal status display | LED |
| DC operating voltage range | 12 V … 26 V |
| Nominal operating voltage DC | 24 V |
| CE marking (see declaration of conformity) | As per EU EMC directive |
| Corrosion resistance class (CRC) | 0 – No corrosion stress |
| Storage temperature | -20 °C … 70 °C |
| Degree of protection | IP40 |
| Ambient temperature | 0 °C … 50 °C |
| Certification | RCM compliance mark |
| Product weight | 3.3 g |
| Electrical connection | 2-pinTwin wireOpen end |
| Cable design | 2 x 0.08 mm² |
| Cable diameter | 1.1 mm |
| Cable length | 0.5 m |
| Protective earth connection | Not available |
| Type of mounting | Push-onEngaging |
| Housing colour | Black |
| Note on materials | RoHS-compliant |
| Housing material | PA-reinforcedPC |
| Weight | 0.011255 lbs |
|---|---|
| Dimensions | 3.346457 × 3.346457 × 0.314961 in |
