| Type code | VACC |
|---|---|
| Actuation type | Electrical |
| Mounting position | Any |
| Switching position indication | no |
| Duty cycle | 100% |
| Insulation class | H |
| Coil characteristics | 60 V AC: 40/65 Hz, power 1.8 VA60 V DC: 1.8 W |
| Permissible voltage fluctuations | -15 % / +10 % |
| ATEX category gas | II 2G |
| Type of ignition protection for gas | Ex eb mb IIC T6, T5, T4 Gb |
| ATEX category for dust | II 2D |
| Type of (ignition) protection for dust | Ex tb IIIC T85°C,T95°C, T130°C Db |
| Explosion protection certification outside the EU | EPL Db (IEC-EX)EPL Gb (IEC-EX) |
| Explosive ambient temperature | T4, T130°C: -30°C <= Ta <= +60°CT5, T95°C: -30°C <= Ta <= +60°CT6, T85°C: -30°C <= Ta <= +50°C |
| Certificate issuing authority | BVS 15ATEXE029XIECEx BVS 15.0075X |
| Explosion prevention and protection | Zone 1 (ATEX)Zone 2 (ATEX)Zone 21 (ATEX)Zone 22 (ATEX)Zone 1 (IEC-EX)Zone 21 (IEC-EX) |
| CE marking (see declaration of conformity) | as per EU explosion protection directive (ATEX) |
| Degree of protection | IP65 |
| Product weight | 330 g |
| Electrical connection | Terminal box, cable entry thread M20x1.5 |
| Note on materials | Contains paint-wetting impairment substancesRoHS-compliant |
| Weight | 0.979073 lbs |
|---|---|
| Dimensions | 6.299213 × 3.346457 × 3.425197 in |
