| Type code | VABS |
|---|---|
| Mounting position | Any |
| Design | Connections rotated 180° |
| Operating pressure | 1.5 bar … 10 bar |
| Operating medium | Compressed air as per ISO 8573-1:2010 [7:-:-] |
| Corrosion resistance class (CRC) | 2 – Moderate corrosion stress |
| Storage temperature | -20 °C … 60 °C |
| Temperature of medium | -20 °C … 60 °C |
| Ambient temperature | -20 °C … 60 °C |
| Product weight | 255.5 g |
| Type of mounting | With through-hole |
| Pneumatic connection 2 | Flange 1/4 with NAMUR port pattern |
| Pneumatic connection 4 | Flange 1/4 with NAMUR port pattern |
| Note on materials | Contains paint-wetting impairment substancesRoHS-compliant |
| Material of sub-base | Wrought aluminum alloy |
| Weight | 0.366761 lbs |
|---|---|
| Dimensions | 2.952756 × 1.968504 × 1.181102 in |
