| Width | 25 mm |
|---|---|
| Mounting position | Any |
| Special features | Oxygen-compatible as per DIN EN 1797 |
| Structural design | Connection direction at side |
| Max. no. of valve positions | 1 |
| Operating pressure | 0 bar … 6 bar |
| Operating medium | Inert gas Air Oxygen |
| Information on operating and pilot media | Operation with oil lubrication not possible Maximum particle size 10 µm |
| Corrosion resistance class (CRC) | 2 – Moderate corrosion stress |
| Storage temperature | -40 °C … 80 °C |
| Temperature of medium | 5 °C … 50 °C |
| Ambient temperature | 5 °C … 50 °C |
| Product weight | 97 g |
| Type of mounting | With through-hole |
| Pneumatic connection 1 | G3/8 |
| Pneumatic connection 2 | G3/8 |
| Note on materials | Contains paint-wetting impairment substances RoHS-compliant |
| Material of sub-base | Wrought aluminum alloy, anodized |
| Weight | 0.228487 lbs |
|---|---|
| Pneumatic connection, port 1 | G3/8 |
| Design | Connection direction at side |
| Material sub-base | Anodised wrought aluminium alloy |
