Valve function | 3/2, open/closed, monostable |
---|---|
Cover material | PA-reinforced |
Lap | Zero overlap |
Max. force on actuator | 200 N |
Max. transverse load on actuator | 200 N |
Operating pressure | -0.095 MPa … 1 MPa |
Actuation type | Manual |
Width | 20 mm |
Standard nominal flow rate | 750 l/min |
Pneumatic working port | 1/8 NPT |
Operating pressure | -0.95 bar … 10 bar |
Design | Plate seat |
Reset method | Mechanical spring |
Nominal width | 5.6 mm |
Type code | VHEF |
Exhaust air function | With flow control option |
Application note | Operate by hand only |
Sealing principle | Soft |
Mounting position | Any |
Type of control | Direct |
Flow direction | Reversible |
Symbol | 00995893 |
Max. switching frequency | 0.5 Hz |
Explosion prevention and protection | Zone 1 (ATEX)Zone 2 (ATEX)Zone 21 (ATEX)Zone 22 (ATEX) |
Operating medium | Compressed air as per ISO 8573-1:2010 [7:-:-] |
Information on operating and pilot media | Operation with oil lubrication possible (required for further use) |
Corrosion resistance class (CRC) | 1 – Low corrosion stress |
Temperature of medium | -10 °C … 60 °C |
Ambient temperature | -10 °C … 60 °C |
Actuating torque | 0.6 Nm |
Product weight | 236 g |
Type of mounting | Front panel mountingWith through-holeOptionally: |
Pneumatic connection 1 | 1/8 NPT |
Pneumatic connection 2 | 1/8 NPT |
Pneumatic connection 3 | 1/8 NPT |
Note on materials | RoHS-compliant |
Seals material | NBR |
Housing material | Wrought aluminum alloy, anodized |
Lever material | PA-reinforced |
