| Nominal width | 6mm |
|---|---|
| Actuation type | Electrical |
| Sealing principle | Soft |
| Mounting position | Any |
| Structural design | Directly controlled poppet valve |
| Reset method | Mechanical spring |
| Type of control | Direct |
| Flow direction | Non-reversible |
| Symbol | 00995953 |
| Valve function | 2/2 proportional directional control valve, closed |
| Operating pressure | 0MPa |
| Operating pressure | 0bar |
| Nominal operating pressure | 0.7MPa |
| Nominal operating pressure | 7bar |
| Nominal operating pressure | 101.5psi |
| Standard flow rate | 270l/min |
| Hysteresis | 22.5mA |
| On switching time | 10ms |
| Current regulating range | 0mA |
| Max. electrical power consumption | 3W |
| Coil resistance | 60.5Ohm |
| Duty cycle | 100% (see assembly instructions) |
| Corrosion resistance class (CRC) | 1 – Low corrosion stress |
| LABS (PWIS) conformity | VDMA24364 zone III |
| Medium | Inert gas |
| Information on medium | Operation with oil lubrication not possible |
| Temperature of medium | 5°C |
| Degree of protection | IP60 |
| Note on degree of protection | IP65 with suitable plug |
| Ambient temperature | 5°C |
| Storage temperature | -40°C |
| Product weight | 25g |
| Electrical connection 1, connection type | Cable |
| Electrical connection 1, connection technology | Open end |
| Electrical connection 1, number of pins/wires | 2 |
| Cable length | 0.07m |
| Type of mounting | On sub-base |
| Pneumatic connection 1 | Cartridge 7.5 mm |
| Pneumatic connection 2 | Cartridge 15 mm |
| Note on materials | RoHS-compliant |
| Seals material | FPM |
| Housing material | High-alloy steel |
| Weight | 0.094799 lbs |
|---|---|
| Dimensions | 7.874016 × 6.692913 × 0.590551 in |
