| Nominal width | 6 mm |
|---|---|
| Actuation type | Electrical |
| Sealing principle | Soft |
| Mounting position | Any |
| Structural design | Directly controlled poppet valve |
| Reset method | Mechanical spring |
| Type of control | Direct |
| Flow direction | Non-reversible |
| Symbol | 00995953 |
| Valve function | 2/2 proportional directional control valve, closed |
| Operating pressure | 0 bar … 3 bar |
| Nominal operating pressure | 2 bar |
| Standard flow rate | 200 l/min … 220 l/min |
| Hysteresis | 22.5 mA |
| Current regulating range | 0 mA … 225 mA |
| Max. electrical power consumption | 3 W |
| Coil resistance | 60.5 Ohm |
| Duty cycle | 100% (operating current < 120 mA) |
| Corrosion resistance class (CRC) | 1 – Low corrosion stress |
| Medium | Inert gas Air Oxygen |
| Information on medium | Operation with oil lubrication not possible Maximum particle size 10 µm |
| Temperature of medium | 5 °C … 50 °C |
| Degree of protection | IP60 |
| Note on degree of protection | IP65 with suitable plug In mounted state |
| Ambient temperature | 5 °C … 50 °C |
| Storage temperature | -40 °C … 80 °C |
| Product weight | 25 g |
| Electrical connection 1, connection type | Cable |
| Electrical connection 1, connection technology | Open end |
| Electrical connection 1, number of pins/wires | 2 |
| Cable length | 0.07 m … 0.08 m |
| Type of mounting | On sub-base Plug-in With accessories |
| Pneumatic connection 1 | Cartridge 7.5 mm |
| Pneumatic connection 2 | Cartridge 15 mm |
| Note on materials | Contains paint-wetting impairment substances RoHS-compliant |
| Seals material | FPM |
| Housing material | High-alloy steel |
| Weight | 0.092594 lbs |
|---|---|
| Dimensions | 5.905512 × 4.724409 × 0.787402 in |
