| Type code | DACS |
|---|---|
| Position sensing | For proximity sensor |
| Mounting position | Any |
| Clamping type with active direction | Both sidesClamped by spring, released by compressed air |
| Symbol | 00992086 |
| Safety function | Holding and stopping a movement |
| Performance Level (PL) | Stopping, holding, blocking of movement/Category 1, Performance Level c |
| Operating pressure | 3.8 bar … 8 bar |
| Max. permissible test pressure | 8 bar |
| Min. release pressure | 3.8 bar |
| Round material to be clamped | 25 mm |
| Certificate issuing authority | TÃœV CA 697 |
| Operating medium | Compressed air as per ISO 8573-1:2010 [7:4:4] |
| CE marking (see declaration of conformity) | as per EU machinery directive |
| Corrosion resistance class (CRC) | 3 – High corrosion stress |
| Ambient temperature | -10 °C … 80 °C |
| Certification | German Technical Control Board (TÃœV) |
| Static holding force | 8200 N |
| Product weight | 12832 g |
| Type of mounting | With internal threadWith accessories |
| Clamping unit release connection | G3/8 |
| Note on materials | RoHS-compliant |
| Seals material | NBRTPE-U(PU) |
| Material of spring | High-alloy steel |
| Housing material | Steel |
| Clamping jaws material | Tool steel |
| Material of piston | Steel |
| Weight | 29.88366 lbs |
|---|---|
| Dimensions | 12.795276 × 9.251969 × 8.267717 in |
