| Type code | VMPA2 |
|---|---|
| Valve function | Unlockable non-return function |
| Actuation type | Pneumatic |
| Type of mounting | Clip |
| Standard nominal flow rate | 330 l/min |
| Operating pressure | 0.5 bar … 8 bar |
| Pilot pressure | 0.5 bar … 8 bar |
| Ambient temperature | -5 °C … 50 °C |
| Housing material | POM |
| Operating medium | Compressed air as per ISO 8573-1:2010 [7:4:4] |
| Mounting position | Any |
| Actuation type, piloted non-return function | Pneumatic |
| Operating pressure for entire temperature range | 0.5 bar … 8 bar |
| Information on operating and pilot media | Operation with oil lubrication possible (required for further use) |
| Corrosion resistance class (CRC) | 4 – Particularly high corrosion stress |
| Storage temperature | -20 °C … 40 °C |
| Temperature of medium | -5 °C … 50 °C |
| Pilot medium | Compressed air as per ISO 8573-1:2010 [7:4:4] |
| Product weight | 0.19 g |
| Note on materials | RoHS-compliant |
| Seals material | NBR |
| Weight | 0.001146 lbs |
|---|---|
| Dimensions | 4.92126 × 3.149606 × 0.07874 in |
