non-return valve VMPA14-RV Valve function=piloted non-return function, Type of actuation=pneumatic, Mounting type=Clip, Standard nominal flow rate=350 l/min, Operating pressure=0,5 – 8 bar
| Valve function | piloted non-return function |
|---|---|
| Type of actuation | pneumatic |
| Mounting type | Clip |
| Standard nominal flow rate | 350 l/min |
| Operating pressure | 0.5 … 8 bar |
| Pilot pressure | 0.5 … 8 bar |
| Ambient temperature | ‘-5 … 50 °C |
| Material housing | POM |
| Operating medium | Compressed air in accordance with ISO8573-1:2010 [7:4:4] |
| Assembly position | Any |
| Type of actuation, controlled non-return function | pneumatic |
| Operating pressure complete temperature range | 0.5 … 8 bar |
| Note on operating and pilot medium | Lubricated operation possible (subsequently required for further operation) |
