| Outside diameter | 22 mm |
|---|---|
| Inside diameter | 18 mm |
| Type code | PAN-R-.-SW |
| Temperature-dependent operating pressure | -0.95 bar … 14 bar |
| Operating medium | Compressed air as per ISO 8573-1:2010 [7:-:-] |
| Ambient temperature | -30 °C … 80 °C |
| Product weight by length | 1.31 kg/m |
| Pneumatic connection | For plug connection outside diameter 22 mm |
| Color | Black |
| Shore hardness | D 62 +/-3 |
| Note on materials | Free of copper and PTFERoHS-compliant |
| Material of pneumatic tubing | TPE-A |
| Weight | 0.299829 lbs |
|---|---|
| Dimensions | 0.984252 in |
| Outside diameter | 22 mm |
| Inside diameter | 18 mm |
| Temperature-dependent operating pressure | -0.95 bar – 14 bar |
| Ambient temperature | -30?C – 80?C |
