| Width | 10 mm |
|---|---|
| Width | 10.7 mm |
| Length | 107.3 mm |
| Width dimension | 10.7 mm |
| Type code | VMPAL |
| Pressure zone separation | Channels 1, 3 and 5 |
| Integrated function | Non-return valve |
| Max. no. of valve positions | 1 |
| Flow direction | Non-reversible |
| Valve manifold design | Valve sizes can be mixed |
| Operating pressure | 0 bar … 10 bar |
| Pilot pressure | 3 bar … 8 bar |
| Suitability for vacuum | no |
| Operating medium | Compressed air as per ISO 8573-1:2010 [7:4:4] |
| Information on operating and pilot media | Operation with oil lubrication possible (required for further use) |
| Corrosion resistance class (CRC) | 3 – High corrosion stress |
| Ambient temperature | -5 °C … 50 °C |
| Product weight | 25 g |
| Pneumatic connection 2 | for 10 mm cartridge |
| Pneumatic connection 4 | For 10 mm cartridge |
| Note on materials | RoHS-compliant |
| Material of sub-base | PA-reinforced |
| Weight | 0.108247 lbs |
|---|---|
| Dimensions | 5.11811 × 2.559055 × 2.165354 in |
