| Width | 44 mm |
|---|---|
| Exhaust air function | Via throttle plate |
| Based on norm | ISO 5599-1 |
| Operating pressure | 0 bar … 10 bar |
| Suitability for vacuum | yes |
| CE marking (see declaration of conformity) | As per EU low voltage directive |
| Operating medium | Compressed air as per ISO 8573-1:2010 [7:4:4] |
| Information on operating and pilot media | Operation with oil lubrication possible (required for further use) |
| Corrosion resistance class (CRC) | 0 – No corrosion stress |
| Storage temperature | -20 °C … 60 °C |
| Temperature of medium | -10 °C … 50 °C |
| Pilot medium | Compressed air as per ISO 8573-1:2010 [7:4:4] |
| Ambient temperature | -10 °C … 50 °C |
| Product weight | 370 g |
| Type of mounting | with through-hole for M6 screw |
| Pilot air port 12/14 | G¼ |
| Pneumatic connection 1 | G3/4 |
| Pneumatic connection 3 | G3/4 |
| Pneumatic connection 5 | G3/4 |
| Note on materials | RoHS-compliant |
| End plate material | Die-cast aluminum |
| Weight | 0.946974 lbs |
|---|---|
| Dimensions | 5.905512 × 3.346457 × 3.346457 in |
