Relative pressure or vacuum transmitter. For optional manifold assembly using a wall bracket.

SKU: 8025977 Category: Tag:
Type code SPTE
KC characters KC EMC
Symbol 992257
Certification RCM compliance markc UL us – Recognized (OL)
CE marking (see declaration of conformity) As per EU EMC directiveAs per EU RoHS directive
Note on materials RoHS-compliant
Measured variable Relative pressure
Method of measurement Piezoresistive pressure sensor
Pressure measuring range initial value -1 bar
Pressure measuring range end value 1 bar
Max. overload pressure 5 bar
Operating medium Compressed air as per ISO 8573-1:2010 [7:4:4]
Information on operating and pilot media Operation with oil lubrication possible
Temperature of medium 0 °C … 50 °C
Ambient temperature 0 °C … 50 °C
Accuracy in ± % FS 3 %FS
Repetition accuracy in ± %FS 0.3 %FS
Temperature co-efficient in ± %FS/K 0.05 %FS/K
Analog output 1 – 5 V
Rise time 1 ms
Min. load resistance of voltage output 15 kOhm
Short-circuit protection For all electrical connections
DC operating voltage range 10 V … 30 V
Electrical connection 3-wireOpen endCable
Cable length 2.5 m
Type of mounting Pin-type conneciton
Mounting position Any
Pneumatic connection Cartridge 10 mm
Product weight 35 g
Housing material PA-reinforced
Sealing ring material NBR
Degree of protection IP40
Corrosion resistance class (CRC) 2 – Moderate corrosion stress
