VPPM-12L-L-1-N12-0L10H-V1P-S1C1

$1,654.67

SKU: 576681
UNSPSC: 40141603
GTIN: 4052568225438

SKU: 576681 Category: Tag: Brand:

The new dimension in the field of proportional pressure control valves. The right parameters for every application – simply select the matching control characteristics from 3 presets at the push of a button. Reliable control – thanks to a two-stage circuit with multi-sensor control.

KC charactersKC EMC
Nominal width pressurization12 mm
Exhaust nominal width12 mm
Type codeVPPM
Actuation typeElectrical
Sealing principleSoft
Mounting positionAny
DesignPilot-controlled diaphragm regulator
Short-circuit protectionFor all electrical connections
Safety instructionsVPPM safety position: if the supply cable breaks, the outlet pressure is maintained in uncontrolled form.
Symbol00995303
Reverse polarity protectionfor all electrical connections
Reset methodMechanical spring
Type of controlPilot-controlled
Valve function3-way proportional pressure control valve
Display typeLED
Pressure regulation range0.1 bar … 10 bar
Inlet pressure 10 bar … 11 bar
Max. pressure hysteresis0.05 bar
Standard nominal flow rate7000 l/min
DC operating voltage range21.6 V … 26.4 V
Max. current consumption500 mA
Duty cycle100%
Max. electrical power consumption12 W
Residual ripple10 %
Switching outputPNP
Analog output signal range4 – 20 mA
Analog input signal range4 – 20 mA
Operating mediumInert gasCompressed air as per ISO 8573-1:2010 [7:4:4]
Information on operating and pilot mediaOperation with oil lubrication not possible
CE marking (see declaration of conformity)As per EU EMC directive
Corrosion resistance class (CRC)2 – Moderate corrosion stress
Temperature of medium10 °C … 50 °C
