| Width dimension | 19 mm |
|---|---|
| Type code | VABM |
| Max. no. of valve positions | 16 |
| Operating pressure | -0.9 bar … 10 bar |
| Corrosion resistance class (CRC) | 2 – Moderate corrosion stress |
| Certification | c UL us – Recognized (OL)c CSA us (OL)RCM compliance mark |
| Max. tightening torque for H-rail mounting: | 1.5 Nm |
| Max. tightening torque for valve mounting | 1.18 Nm |
| Max. tightening torque for wall mounting | 3 Nm |
| Product weight | 439 g |
| Pneumatic connection 1 | G3/8 |
| Pneumatic connection 3 | G3/8 |
| Pneumatic connection 5 | G3/8 |
| Note on materials | RoHS-compliant |
| Manifold rail material | Wrought aluminum alloy |
| Weight | 1.077179 lbs |
|---|---|
| Dimensions | 5.11811 × 4.251969 × 2.992126 in |
