| Contamination level | 3 |
|---|---|
| Surge resistance | 0.8 kV |
| Type code | VAVE |
| Mounting position | Any |
| Cable characteristic | for static applications |
| Reverse polarity protection | Bipolar |
| Additional functions | Holding current reductionSpark suppression |
| Signal status display | LED |
| Nominal operating voltage DC | 24 V |
| CE marking (see declaration of conformity) | As per EU EMC directive |
| Corrosion resistance class (CRC) | 0 – No corrosion stress |
| Degree of protection | IP65 |
| Ambient temperature | -5 °C … 60 °C |
| Certification | RCM compliance mark |
| Max. tightening torque | 0.27 Nm |
| Min. cable bending radius | 34 mm |
| Product weight | 20 g |
| Electrical connection | 2-pin/2-wireRectangular design/open endAngled socket/cable |
| Cable design | 2 x 0.25 mm² |
| Cable diameter | 3.4 mm |
| Cable diameter tolerance | ± 0.2 mm |
| Cable length | 1 m |
| Protective earth connection | Not available |
| Housing colour | Black |
| Note on materials | RoHS-compliant |
| Housing material | PA |
| Material of cable sheath | TPV |
| Weight | 0.050221 lbs |
|---|---|
| Dimensions | 4.724409 × 5.708661 × 0.393701 in |
