| Contamination level | 3 |
|---|---|
| Surge resistance | 0.8 kV |
| Type code | VAVE |
| Mounting position | Any |
| Cable characteristic | for static applications |
| Reverse polarity protection | Bipolar |
| Additional functions | Spark suppression |
| Signal status display | LED |
| Nominal operating voltage DC | 24 V12 V |
| Corrosion resistance class (CRC) | 0 – No corrosion stress |
| Degree of protection | IP65 |
| Ambient temperature | -5 °C … 60 °C |
| Max. tightening torque | 0.27 Nm |
| Min. cable bending radius | 34 mm |
| Product weight | 92 g |
| Electrical connection | Angled socket/cable2-pin/2-wireRectangular design/open end |
| Cable design | 2 x 0.25 mm² |
| Cable diameter | 3.4 mm |
| Cable diameter tolerance | ± 0.2 mm |
| Cable length | 5 m |
| Protective earth connection | Not available |
| Type of mounting | On air solenoid valve with self-tapping screw |
| Housing colour | Black |
| Housing material | PA |
| Material of cable sheath | TPV |
| Weight | 0.193786 lbs |
|---|---|
| Dimensions | 8.267717 × 5.511811 × 1.181102 in |
