| Type code | MN1H |
|---|---|
| Design | Diaphragm valve |
| Sealing principle | Soft |
| Mounting position | Any |
| Type of mounting | Line installation |
| Fitting connection | 3/8 NPT |
| Nominal width | 13 mm |
| Valve function | 2/2, closed, monostable |
| Manual override | Non-detentingDetenting via accessory |
| Flow direction | Non-reversible |
| Medium | Filtered compressed air, 200 µm filter mesh |
| Exhaust air function | Without flow control option |
| Reset method | Pneumatic spring |
| Type of control | Pilot-controlled |
| Symbol | 00991399 |
| Medium pressure | 0.5 bar … 10 bar |
| Information on operating and pilot media | Operation with oil lubrication possible (required for further use) |
| Temperature of medium | -10 °C … 60 °C |
| Ambient temperature | -10 °C … 60 °C |
| Material of screws | High-alloy stainless steel |
| Material number of screw | 1.4301 |
| Product weight | 450 g |
| Degree of protection | IP65 |
| Weight | 2.77562 lbs |
|---|---|
| Dimensions | 5.314961 × 4.330709 × 3.740157 in |
