analogue module CPX-4AE-T for modular electrical terminal CPX. Permits connection of four temperature sensors for temperature measurement ranging from -200°C to 850°C. Dimensions W x L x H=(* (incl. interlinking block and connection technology), * 50 mm x 107 mm x 50 mm), No. of inputs=4, Diagnosis=(* – Wire break per channel, * – Limit value violation per channel, * – Short circuit input signal, * – Parameterisation error), Parameters configuring=(* Forces per channel, * – Limit monitoring/channel, * – Unit of measurement, * – Measured value smoothing, * – Sensor type per channel, * Monitoring of wire break/channel), LED displays=(* – 1 Group diagnosis, * – 4 Channel diagnosis)
| Dimensions W x L x HÂ | (incl. interlinking block and connection technology)50 mm x 107 mm x 50 mm |
|---|---|
| No. of inputs | 4 |
| Diagnosis | ‘- Wire break per channel- Limit value violation per channel- Short circuit input signal- Parameterisation error |
| Parameters configuring | Forces per channel- Limit monitoring/channel- Unit of measurement- Measured value smoothing- Sensor type per channelMonitoring of wire break/channel |
| LED displays | ‘- 1 Group diagnosis- 4 Channel diagnosis |
| Internal cycle time | 250 ms |
| Repetition accuracy | 0.05% at 25º C |
| Protection (short circuit)Â | Internal electronic fuse |
| Operating voltage range DCÂ | 18 … 30 V |
| Intrinsic current consumption at operating voltage | Typically 50 mA |
| Operating error limit related to the ambient temperature range | ‘+/- 0,6 % |
| Basic error limit at 25°C | ‘+/- 0.6 K for Pt sensors |
| Nominal operating voltage DCÂ | 24 V |
