ball valve actuator unit VZPR-BPD-22-R2 Comprising pneumatic DAPS quarter turn actuator, combined with a 2/2-way VAPB ball valve in brass version. Design structure=(* 2-way ball valve, * Swivel drive), Type of actuation=(* electrical, * pneumatic), Assembly position=Any, Mounting type=(* CNOMO, * with internal (female) thread), Process valve connection=Rp2
| Design structure | 2-way ball valveSwivel drive |
|---|---|
| Type of actuation | electricalpneumatic |
| Assembly position | Any |
| Mounting type | CNOMOwith internal (female) thread |
| Process valve connection | Rp2 |
| Switching position indicator | Knob direction = Flow direction |
| Nominal diameter DNÂ | 50 |
| Operating pressure, ball valve drive | 1 … 8.4 bar |
| Nominal pressure of process valve | 25 |
| Medium temperature | ‘-20 … 150 °C |
| Ambient temperature | ‘-20 … 80 °C |
| Materials note | Contains PWIS substances |
| Product weight | 5,400 g |
