electrical module VMPA2-MPM-EMM-4 For valve terminal MPA-S with modular multi-pin plug connection, for 4 solenoid coils. Max. number of valve positions=2, Max. number of solenoid coils=4, Nominal breakaway current per solenoid coil=100 mA up to 30 ms, Nominal current with current reduction=20 mA after 30 ms, Corrosion resistance classification CRC=(* 1 – Low corrosion stress, * (when installed))
| Max. number of valve positions | 2 |
|---|---|
| Max. number of solenoid coils | 4 |
| Nominal breakaway current per solenoid coil | 100 mA up to 30 ms |
| Nominal current with current reduction | 20 mA after 30 ms |
| Corrosion resistance classification CRCÂ | 1 – Low corrosion stress(when installed) |
| Product weight | 20 g |
| Material housing | POM |
| Materials note | Conforms to RoHS |
