linear/swivel clamp CLR-12-10-L-P-A Clamping system with linear and swivel motion, 90° to the left Total stroke=19 mm, Piston diameter=12 mm, Piston rod thread=M3, Swivel angle=90 deg +/- 4 deg, Clamping stroke=10 mm
| Total stroke | 19 mm |
|---|---|
| Piston diameter | 12 mm |
| Piston rod thread | M3 |
| Swivel angle | 90 deg +/- 4 deg |
| Clamping stroke | 10 mm |
| Cushioning | P: Flexible cushioning rings/plates at both ends |
| Assembly position | Any |
| Design structure | PistonPiston rodCylinder barrel |
| Position detection | For proximity sensor |
| Swivel direction | Left |
| Operating pressure | 2 … 10 bar |
| Mode of operation | double-acting |
| Operating medium | Compressed air in accordance with ISO8573-1:2010 [7:4:4] |
