MS6N-LRB-1/2-D5-A4-AS

$82.51

SKU: 531830
UNSPSC: 27131603
GTIN:

SKU: 531830 Category: Tag:
Festo

pressure regulator MS6N-LRB-1/2-D5-A4-AS For manifold assembly, maximum output pressure 4 bar, with adapter G1/8 for pressure gauge acc. to EN 837, port P2 on reverse side. Size=6, Series=MS, Actuator lock=(* Rotary knob with lock, * with accessories, lockable), Assembly position=Any, Design structure=(* directly-controlled diaphragm regulator, * with looped-through compressed air supply)

Size  6
Series  MS
Actuator lock  Rotary knob with lockwith accessories, lockable
Assembly position  Any
Design structure  directly-controlled diaphragm regulatorwith looped-through compressed air supply
Controller function  Output pressure constantwith initial pressure compensationwith secondary exhaust
Pressure gauge  Prepared for G1/4
Operating pressure  0.8 … 20 bar
Pressure regulation range  0.3 … 4 bar
Max. pressure hysteresis  0.25 bar
Standard nominal flow rate  7,300 l/min
Operating medium  Compressed air in accordance with ISO8573-1:2010 [7:4:4]Inert gases
Note on operating and pilot medium  Lubricated operation possible (subsequently required for further operation)
Size

6

Series

MS

Actuator lock

Rotary knob with lockwith accessories, lockable

Assembly position

Any

Design structure

directly-controlled diaphragm regulatorwith looped-through compressed air supply

Controller function

Output pressure constantwith initial pressure compensationwith secondary exhaust

Pressure gauge

Prepared for G1/4

Operating pressure

0.8 … 20 bar

Pressure regulation range

0.3 … 4 bar

Max. pressure hysteresis

0.25 bar

Standard nominal flow rate

7,300 l/min

Operating medium

Compressed air in accordance with ISO8573-1:2010 [7:4:4]Inert gases

Note on operating and pilot medium

Lubricated operation possible (subsequently required for further operation)
