connecting cable KMP6-09P-8-2,5 For miniature valves, with Sub-D, 9-pin for 8 coils. Mounting type=with through hole, Assembly position=Any, Product weight=248 g, Electrical connection=(* Plug socket, * Sub-D, * 9-pin), Operating voltage range DC=<= 24 V
| Mounting type | with through hole |
|---|---|
| Assembly position | Any |
| Product weight | 248 g |
| Electrical connection | Plug socketSub-D9-pin |
| Operating voltage range DCÂ | <= 24 V |
| Permissible current load | 2.8 A |
| Cable length | 2.5 m |
| Cable diameter | 7.6 mm |
| Cable structure | 8×0,34+1×0,5 |
| Protection class | IP40 |
| Ambient temperature | ‘-30 … 80 °C |
| Ambient temperature with flexible cable installation | ‘-5 … 80 °C |
| Material cable sheath | PVC |
