analogue module CPX-2AA-U-I for modular electrical terminal CPX, 2 outputs. Dimensions W x L x H=(* (incl. interlinking block and connection technology), * 50 mm x 107 mm x 50 mm), No. of outputs=2, Diagnosis=(* – Wire break per channel, * – Limit value violation per channel, * – Short circuit output signal per channel, * – Short circuit actuator supply, * – Parameterisation error, * – Undervoltage of outputs), Parameters configuring=(* – Data format, * Failsafe per channel, * Forces per channel, * – Limit monitoring/channel, * Idle mode per channel, * – Measured value smoothing, * – Signal range per channel, * – Behaviour after short circuit, * Monitoring of wire break/channel), LED displays=- 1 Group diagnosis
| Dimensions W x L x HÂ | (incl. interlinking block and connection technology)50 mm x 107 mm x 50 mm |
|---|---|
| No. of outputs | 2 |
| Diagnosis | ‘- Wire break per channel- Limit value violation per channel- Short circuit output signal per channel- Short circuit actuator supply- Parameterisation error- Undervoltage of outputs |
| Parameters configuring | ‘- Data formatFailsafe per channelForces per channel- Limit monitoring/channelIdle mode per channel- Measured value smoothing- Signal range per channel- Behaviour after short circuitMonitoring of wire break/channel |
| LED displays | ‘- 1 Group diagnosis |
| Internal cycle time | 4 ms |
| Repetition accuracy | 0.05% at 25º C |
| Protection (short circuit)Â | Internal electronic fuse |
| Operating voltage range DCÂ | 18 … 30 V |
| Intrinsic current consumption at operating voltage | Typ. 100 mA |
| Operating error limit related to the ambient temperature range | ‘+/- 0,6 % |
| Basic error limit at 25°C | ‘+/- 0,5 % |
| Nominal operating voltage DCÂ | 24 V |
