bellows cylinder EB-80-20 Maintenance-free, no stick/slip effect. Size=80, Required installation diameter=95 mm, Stroke=20 mm, Max height when extended=70 mm, Max. tipping angle=10 deg
| Size | 80 |
|---|---|
| Required installation diameter | 95 mm |
| Stroke | 20 mm |
| Max height when extended | 70 mm |
| Max. tipping angle | 10 deg |
| Max. offset | 5 mm |
| Min. installation height | 50 mm |
| Mode of operation | single-acting |
| Operating pressure | 0 … 8 bar |
| Operating medium | Compressed air to ISO 8573-1:2010 [-:-:4] |
| Note on operating and pilot medium | Lubricated operation not possible |
| Corrosion resistance classification CRCÂ | 0 – No corrosion stress |
| Ambient temperature | ‘-40 … 70 °C |
