| Working length | 2 m |
|---|---|
| Outside diameter | 10 mm |
| Block length | 0.66 m |
| Inside diameter | 7 mm |
| Winding diameter | 80 mm |
| Number of windings | 22 |
| Type code | PUN-S-DUO |
| Temperature-dependent operating pressure | -0.95 bar … 10 bar |
| Operating medium | Compressed air as per ISO 8573-1:2010 [7:-:-] |
| Ambient temperature | -35 °C … 60 °C |
| Certification | German Technical Control Board (TÃœV) |
| Product weight | 490 g |
| Pneumatic connection | For plug connection outside diameter 10 mm |
| Color | Blue/black |
| Shore hardness | D 52 +/-3 |
| Note on materials | Free of copper and PTFE |
| Material of pneumatic tubing | TPE-U(PU) |
| Weight | 1.278681 lbs |
|---|---|
| Dimensions | 22.440945 × 0.393701 × 2.755906 in |
| Outside diameter | 10 mm |
| Inside diameter | 7 mm |
| Working length | 2 m |
| Temperature-dependent operating pressure | -0.95 bar – 10 bar |
| Ambient temperature | -35?C – 60?C |
