LF-D-5M-MIDI-A

$174.00

SKU: 192561 Category: Tag:
Festo

filter
LF-D-5M-MIDI-A
Part number: 192561

Classic

Without threaded connection plates with FRB threaded pin. Degree of filtration: 5 µm, with bowl guard and automatic condensate drain.

Modern alternatives can be found by entering the first four characters of the type code in the search field.

Size  Midi
Series  D
Assembly position  Vertical +/- 5°
Grade of filtration  5 µm
Condensate drain  fully automatic
Design structure  Sintered filter with centrifugal separator
Max. condensate volume  43 cm3
Bowl guard  Metal bowl guard
Operating pressure  2 … 12 bar
Operating medium  Compressed air to ISO 8573-1:2010 [7:9:-]Inert gases
Corrosion resistance classification CRC  2 – Moderate corrosion stress
Storage temperature  ‘-10 … 60 °C
Air purity class at output  Compressed air in accordance with ISO8573-1:2010 [6:8:4]Inert gases
Size

Midi

Series

D

Assembly position

Vertical +/- 5°

Grade of filtration

5 µm

Condensate drain

fully automatic

Design structure

Sintered filter with centrifugal separator

Max. condensate volume

43 cm3

Bowl guard

Metal bowl guard

Operating pressure

2 … 12 bar

Operating medium

Compressed air to ISO 8573-1:2010 [7:9:-]Inert gases

Corrosion resistance classification CRC

2 – Moderate corrosion stress

Storage temperature

-10 … 60 °C

Air purity class at output

Compressed air in accordance with ISO8573-1:2010 [6:8:4]Inert gases
