displacement encoder
MLO-POT-150-LWG
Part number: 192214
| CE mark (see declaration of conformity) | to EU directive for EMC |
|---|---|
| Measuring method: displacement encoder | Analogue |
| Ambient temperature | ‘-30 … 100 °C |
| Recommended wiper current | < 1 µA |
| Max. intermittent wiper current | 10 mA |
| Max. travel speed | 5 m/s |
| Max. travel acceleration | 200 m/s2 |
| Travel resolution | 0.01 mm |
| Independent linearity | 0,08 % |
| Temperature coefficient | 5 ppm/K |
| Stroke | 150 mm |
| Output signal | Analogue |
| Connection resistance | 5 kOhm |
| Weight | 1.46905 lbs |
|---|---|
| Dimensions | 16.732283 × 3.464567 × 3.149606 in |
| Stroke | 150 mm |
| Functional principle of measuring system | Analogue |
| Output signal | Analogue |
| Displacement resolution | 0.01 mm |
| Electrical connection | 16 mm – 4-pin – Plugs – Square design |
