suction cup ESS-6-SS Wearing part, easily replaceable Min. workpiece radius=15 mm, Nominal size=2 mm, suction cup diameter=6 mm, suction cup volume=0,015 cm3, Ejector pulse suitability=<= 4 bar
| Min. workpiece radius | 15 mm |
|---|---|
| Nominal size | 2 mm |
| suction cup diameter | 6 mm |
| suction cup volume | 0.015 cm3 |
| Ejector pulse suitability | <= 4 bar |
| Position of connection | on top |
| Assembly position | Any |
| Correlation to suction-cup holder | Size 2 |
| Suction cup shape | round flat |
| Operating pressure | 0 … 0.95 bar |
| Nominal operating pressure | ‘-0.7 bar |
| Operating medium | Atmospheric air based on ISO 8573-1:2010 [7:-:-] |
| Corrosion resistance classification CRCÂ | 1 – Low corrosion stress |
