MPPES-3-1/2-6-420

$1,871.26

SKU: 187331
UNSPSC: 40141603
GTIN: 4052568148003

SKU: 187331 Category: Tag:
Festo

The new dimension in the field of proportional pressure control valves. The right parameters for every application – simply select the matching control characteristics from 3 presets at the push of a button. Reliable control – thanks to a two-stage circuit with multi-sensor control.

KC characters KC EMC
Nominal width pressurization 6 mm
Exhaust nominal width 4.5 mm
Type code VPPM
Actuation type Electrical
Sealing principle Soft
Mounting position Any
Design Pilot-controlled diaphragm regulator
Short-circuit protection For all electrical connections
Safety instructions VPPM safety position: if the supply cable breaks, the outlet pressure is maintained in uncontrolled form.
Symbol 00995303
Reverse polarity protection for all electrical connections
Reset method Mechanical spring
Type of control Pilot-controlled
Valve function 3-way proportional pressure control valve
Display type LED
Pressure regulation range 0.1 bar … 10 bar
Inlet pressure 1 0 bar … 11 bar
Max. pressure hysteresis 0.05 bar
Standard nominal flow rate 1400 l/min
DC operating voltage range 18 V … 30 V
Max. current consumption 300 mA
Duty cycle 100%
Max. electrical power consumption 7 W
Protocol IO-Link®I-Port
Residual ripple 10 %
Operating medium Inert gasCompressed air as per ISO 8573-1:2010 [7:4:4]
Information on operating and pilot media Operation with oil lubrication not possible
CE marking (see declaration of conformity) As per EU EMC directive
Corrosion resistance class (CRC) 2 – Moderate corrosion stress
Temperature of medium 10 °C … 50 °C
Degree of protection IP65
Ambient temperature 0 °C … 60 °C
