vacuum generator CPV10-M1H-VI70-2GLS-M7 With ejector pulse Nominal size, Laval nozzle=0,7 mm, Assembly position=Any, Ejector characteristic=High vacuum, Operating pressure=2 – 10 bar, Max. vacuum=85 %
| Nominal size, Laval nozzle | 0.7 mm |
|---|---|
| Assembly position | Any |
| Ejector characteristic | High vacuum |
| Operating pressure | 2 … 10 bar |
| Max. vacuum | 0.85 |
| Operating medium | Compressed air in accordance with ISO8573-1:2010 [7:4:4] |
| Note on operating and pilot medium | Lubricated operation possible (subsequently required for further operation) |
| Corrosion resistance classification CRCÂ | 1 – Low corrosion stress |
| Medium temperature | 0 … 50 °C |
| Ambient temperature | 0 … 50 °C |
| Electrical connection | Plug |
| Mounting type | with through hole |
| Pneumatic connection, port 1Â | Sub-base |
