| Size | 8 |
|---|---|
| Max. gripper jaw angular play ax, ay | 0.5 deg |
| Max. gripper jaw backlash Sz | 0.03 mm |
| Max. opening angle | 17 deg |
| Pneumatic gripper repetition accuracy | ≤0.02 mm |
| Number of gripper jaws | 2 |
| Actuator system | Pneumatic |
| Mode of operation | Single-acting | Open |
| Gripper function | Angle |
| Gripping force backup | Without |
| Structural design | Inclined plane |
| Position sensing | None |
| Symbol | 00991897 |
| Operating pressure | 2 bar … 8 bar |
| Max. operating frequency of pneumatic gripper | 4 Hz |
| Min. opening time at 6 bar | 2.7 ms |
| Min. closing time at 6 bar | 1.2 ms |
| Operating medium | Compressed air as per ISO 8573-1:2010 [7:-:-] |
| Corrosion resistance class (CRC) | 2 – Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B2-L |
| Ambient temperature | 5 °C … 60 °C |
| Spring return torque | 0.005 Nm |
| Total gripping torque at 6 bar, closing | 22 Ncm |
| Mass moment of inertia | 31.5 kgcm² |
| Mass moment of inertia per external gripper finger | 250 kgcm² |
| Maximum force on gripper jaw Fz, static | 7 N |
| Maximum torque on gripper jaw, Mx static | 0.2 Nm |
| Maximum torque on gripper jaw, My static | 0.2 Nm |
| Maximum torque on gripper jaw, Mz static | 0.2 Nm |
| Max. mass per external gripper finger | 400 g |
| Product weight | 14 g |
| Type of mounting | With lock nut |
| Pneumatic connection | M3 |
| Note on materials | RoHS-compliant |
| Cover cap material | POM |
| Housing material | High-alloy stainless steel |
| Gripper jaw material | High-alloy steel |
| Weight | 0.244713 lbs |
|---|---|
| Dimensions | 2.716535 × 2.165354 × 4.566929 in |
| Size | 8 |
| Max. gripper jaw angular play ax, ay | 0.5 deg |
| Max. gripper jaw backlash Sz | 0.03 mm |
| Max. opening angle | 17 deg |
| Pneumatic gripper repetition accuracy | ≤0.02 mm |
| Number of gripper jaws | 2 |
| Actuator system | Pneumatic |
| Mode of operation | Single-acting, Open |
| Gripper function | Angle |
| Gripping force backup | Without |
| Structural design | Inclined plane |
| Position sensing | None |
| Symbol | 00991897 |
| Operating pressure | 2 bar … 8 bar |
| Max. operating frequency of pneumatic gripper | 4 Hz |
| Min. opening time at 6 bar | 2.7 ms |
| Min. closing time at 6 bar | 1.2 ms |
| Operating medium | Compressed air as per ISO 8573-1:2010 [7:-:-] |
| Corrosion resistance class (CRC) | 2 – Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B2-L |
| Ambient temperature | 5 °C … 60 °C |
| Spring return torque | 0.005 Nm |
| Total gripping torque at 6 bar, closing | 22 Ncm |
| Mass moment of inertia | 31.5 kgcm² |
| Mass moment of inertia per external gripper finger | 250 kgcm² |
| Maximum force on gripper jaw Fz, static | 7 N |
| Maximum torque on gripper jaw, Mx static | 0.2 Nm |
| Maximum torque on gripper jaw, My static | 0.2 Nm |
| Maximum torque on gripper jaw, Mz static | 0.2 Nm |
| Max. mass per external gripper finger | 400 g |
| Product weight | 14 g |
| Type of mounting | With lock nut |
| Pneumatic connection | M3 |
| Note on materials | RoHS-compliant |
| Cover cap material | POM |
| Housing material | High-alloy stainless steel |
| Gripper jaw material | High-alloy steel |
