| Type code | KP |
|---|---|
| Mounting position | Any |
| Clamping type with active direction | Clamped by spring, released by compressed airBoth sides |
| Design | Hinge-down panes |
| Variants | Piston rod at one end |
| Operating pressure | ≤ 10 bar |
| Min. release pressure | 3 bar |
| Round material to be clamped | 16 mm |
| Operating medium | Compressed air as per ISO 8573-1:2010 [7:4:4] |
| Information on operating and pilot media | Operation with oil lubrication possible (required for further use) |
| Corrosion resistance class (CRC) | 2 – Moderate corrosion stress |
| Ambient temperature | -10 °C … 80 °C |
| Static holding force | 1000 N |
| Product weight | 90 g |
| Seals material | NBRTPE-U(PU) |
| Material of spring | Spring steel |
| Housing material | AluminumAnodized |
| Clamping jaws material | Brass |
| Material of piston | POM |
KP
KP-16-1000
$507.81
For self-construction of locking units. Not certified for use in safety-relevant controllers
| Weight | 0.242266 lbs |
|---|---|
| Dimensions | 3.543307 × 0.984252 × 0.984252 in |
