SLS

SLS-10-10-P-A

Name: SLS-10-10-P-A
Brand: Festo
SKU: 170492
Availability: InStock

$650.71

SKU: 170492
UNSPSC: 31251504
GTIN: 4052568138981

SKU: 170492 Category: SLS Tag: 2021u

SLT-SLS-SLF_ENUS.PDF

Brand: Festo

mini slide SLS-10-10-P-A Slim design with precision ball-bearing guide. Stroke=10 mm, Piston diameter=10 mm, Operating mode of drive unit=Yoke, Cushioning=P: Flexible cushioning rings/plates at both ends, Assembly position=Any

Stroke	10 mm
Piston diameter	10 mm
Operating mode of drive unit	Yoke
Cushioning	P: Flexible cushioning rings/plates at both ends
Assembly position	Any
Guide	Ball bearing cage guide
Design structure	Yoke kinematics
Position detection	For proximity sensor
Operating pressure	1 … 10 bar
Mode of operation	double-acting
Operating medium	Compressed air in accordance with ISO8573-1:2010 [7:4:4]
Note on operating and pilot medium	Lubricated operation possible (subsequently required for further operation)
Corrosion resistance classification CRC	0 – No corrosion stress

Weight	0.373309 lbs
Dimensions	2.598425 × 1.141732 × 3.267717 in
Piston diameter	10 mm
Theoretical force at 0.6 MPa (6 bar, 87 psi), advance stroke	47 N
Stroke	10 mm
Cushioning	Elastic cushioning rings/plates at both ends
Position detection	Via proximity switch
