flat cylinder EZH-2,5/9-10-B Non-rotating Stroke=10 mm, Piston diameter=(* 6 mm, * Equivalent diameter), Cushioning=No cushioning, Assembly position=Any, Mode of operation=(* single-acting, * pushing action)
| Stroke | 10 mm |
|---|---|
| Piston diameter | 6 mmEquivalent diameter |
| Cushioning | No cushioning |
| Assembly position | Any |
| Mode of operation | single-actingpushing action |
| Design structure | PistonSquare piston rod |
| Position detection | No |
| Protection against torque/guide | Square piston rod |
| Operating pressure | 2.8 … 6 bar |
| Operating medium | Compressed air in accordance with ISO8573-1:2010 [7:4:4] |
| Note on operating and pilot medium | Lubricated operation possible (subsequently required for further operation) |
| Corrosion resistance classification CRCÂ | 2 – Moderate corrosion stress |
| Ambient temperature | 0 … 60 °C |
